This fully automatic sealing & shrink wrapping machine integrates automatic side sealing and heat shrink packaging. Products are conveyed automatically for film wrapping, continuous edge sealing and cutting, then transferred into the thermal shrink tunnel. Uniform hot air circulation tightens the shrink film closely against goods, achieving neat, dust-proof and aesthetic packaging effect.
Adopt advanced constant-temperature sealing system with stable sealing line, no film sticking or breakage. Independent temperature and speed control allows flexible adjustment to suit POF, PVC and other shrinkable films.
Compact structure with smooth running performance, widely applicable for coffee boxes, paper boxes, daily goods and other regular-shaped products. Ideal for medium & large volume continuous packaging production. Custom working size is supported.
| Model | TCH-FA-SHRINK FILM | Power | 1.1 KW |
| Max. Sealing & Cutting Size | Unlimited length × 300 × 180 mm | Conveyor Belt Width | 330 mm |
| Max. Film Width | 550 mm | Overall Dimensions | 1680 × 900 × 1450 mm |
| Sealing & Cutting Speed | 10-30 pcs/min | Packaging Material | POF Film |
| Net Weight & Gross Weight | 310 kg & 350kg | Wooden Package Dimensions | 1820 × 1005 × 1615 mm |
Fully automatic operation, stable and efficient sealing and cutting.
Suitable for POF shrink film, good sealing effect and beautiful packaging.
Unlimited length packaging, strong adaptability to different products.
Stable conveying system, smooth operation and low failure rate.
Compact structure, easy to operate and maintain.
Standard export wooden packaging, safe for long-distance transportation.
Widely used in automatic shrink film packaging of food, daily necessities, stationery, hardware, small boxes and other regular items.
Q: What film is suitable for this machine?
A: Only suitable for POF shrink film, not for PE/PVC film.
Q: What is the maximum packaging size?
A: Unlimited length, width ≤300 mm, height ≤180 mm.
Q: What is the working speed?
A: 10-30 pieces per minute, depending on product size.
Q: Does it need extra air supply?
A: Standard model only needs power; no extra air supply required.
Q: What is the power supply?
A: Normally 220V/380V can be customized according to customer demand.
Q: Can it pack products of different lengths?
A: Yes, length is unlimited, widely applicable.
Q: How about installation and commissioning?
A: Simple structure, easy to install; we provide operation instructions and guidance.
Q: What is the warranty period?
A: Standard 12-month warranty, lifelong technical support and spare parts supply.
Q: Can it be customized?
A: Support size, speed, voltage and other customization.
Q: What is the package for transportation?
A: Export standard wooden case, size 1820×1005×1615 mm, gross weight 350 kg.
Professional packaging machinery manufacturer
Stable performance, high cost performance
Fully automatic, labor-saving and efficient
Suitable for small and medium batch production
Perfect after-sales service and technical support
